Bosch Solution 6000 External Smartcard Reader, CP156B

SKU F.01U.359.721 CP156B
by Bosch
Availability:
in stock, ready to be shipped

Bosch Solution 6000 External Smartcard Reader

Model : CP156B

The CP156B keypad provides alarm and or access control functionality when used on selected Solution security control panels. It is fitted with built in smart prox reader, front and rear tamper. Constructed from high strength zinc alloy die cast housing, the CP156B keypad provides a high level of durability and is also weather resistant to IP65 making it ideal for external installations.

Features :

  • Indoor and outdoor use
  • Weather and Vandal Resistant with IP67 rating
  • Chrome Plated Zinc Die-Cast Finish
  • Backlit with Blue led light
  • Buy genuine buy from ctc communications. See attached pdf for more information
  • Programmable egress input and lock output
  • LED indicator to show alarm stature
  • Reporting and logs
  • Encrypted LAN communication with Bosch solution 6000 panel
Save 23% Save 23%
Original price $514.58
Original price $514.58 - Original price $514.58
Original price $514.58
Current price $395.83
$395.83 - $395.83
Current price $395.83

✓ Flat Rate Shipping $17.50 ✓ Free Delivery over $500

Shipping

Shipping Policy

Free Shipping

  • Free shipping for orders over $500.00.

Postage Charge

  • We charge a flat rate of AUD $17.50 for every order regardless of quantity.

Delivery Policy

  • All prices displayed on this website exclude shipping costs

Delivery Method

  • C.T.C Communications delivers products Australia wide using Australia Post delivery service.

International Shipping

  • We currently do not ship good overseas.

Parcel Tracking

  • All packages sent are registered with Australia Post E Parcel service and provide full tracking once it leaves our premises until it arrives at its destination. A signature on arrival is necessary for shipment.
  • Please ensure your mobile number and emails are entered into your order to help us with this automated tracking service.
Delivery Times

Delivery Times

  • Orders are dispatched within 2 business days and shipping times are estimated at between 3-7 business days depending on your location within Australia.

Transit Times

  • We are not responsible for Australia Post transit times as they do vary depending upon your destination.

Dispatch Times

  • Australia Post picks up from our office is at 2:30pm weekdays, orders placed after 2:30pm that day will not be in the post until the following day.

Public Holidays and Weekends

  • Please note, no goods are dispatched on weekends or public holidays.

Express Post

  • Express orders shall be dispatched within 24-48 working hrs. Staff will be in contact if there is any delay. Delivery time will be dependent of your location within Australia. .

P.O Box Delivery

  • We delivery to PO Boxes and Parcel Lockers but ideally work addresses are more suitable for a signed delivery.

Business to Business with Sydney

  • For companies in Sydney we utilise our local courier service Couriers Please.

Pick up in-store

  • Pick up is available at our Seven Hills showroom, Unit 31/1 Prime Drive, Seven Hills, NSW, 2147.

Urgent Deliveries

  • If you require this parcel urgently please call our office on 1300 552 282 to ensure all items are in stock prior to purchasing.
Refund Policy

Trade Accounts

To learn more about our trade accounts and how you can save money on your next security purchase.

Apply Now


osch CP156B weather resistant slimline code pad provides alarm and access control functionality when used with the Solution 6000 control panel.

Model : CP156B

The CP156B keypad provides alarm and or access control functionality when used on selected Solution security control panels.

Features :

  • Indoor and outdoor use
  • Weather and Vandal Resistant with IP67 rating
  • Chrome Plated Zinc Die-Cast Finish
  • Backlit with Blue led light
  • Buy genuine buy from CTC Communications. See attached pdf for more information
  • Programmable egress input and lock output
  • LED indicator to show alarm stature
  • Reporting and logs
  • Encrypted LAN communication with Bosch solution 6000 panel

It is fitted with built in smart prox reader, front and rear tamper. Constructed from high strength zinc alloy die cast housing, the CP156B keypad provides a high level of durability and is also weather resistant to IP65 making it ideal for external installations.

The CP156B includes red, green and blue indicators which are used to show area or door lock status. Backlit buttons make it easy to operate in all lighting conditions.

The keypad connects to the control panel via the RS485 encrypted LAN and occupies a standard keypad position in the panel configuration. Various keypad options can be configured via the Devices - Keypad & Readers menu in panel programming. User access events are stored in the panel log and can also be reported if required.

Specifications

  • Part Number : CP156B - External 6x2 Metal Keypad With Smart Card Reader (IP67).
  • Operating Voltage: 10.0V D.C. - 14.5V D.C. @ 100mA Max.
  • Module Connection: (RS485 LAN) Max total LAN length using multi strand security cable = 500m. Max total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m. See the control panel manual for complete wiring instructions.
  • Lock Output: Relay 2Amp DC
  • Egress Input: Low to trigger. Can be disabled via software control.
  • Dimensions: 45mm(W), 23mm(D), 162mm(H). CM444B = 46mm(W), 12.5mm(D), 12mm H)
  • Environment: -30 to 55C RH 5 to 85% at 30C non-condensing.
  • Fixing Method: The CP156B should be mounted on a sturdy vertical wall using fixtures appropriate for the wall construction type.



    Optional for Bosch Solution 6000 Alarm Systems

    Connect to the MyAlarm cloud security service to make use of the iFob Control app available on both IOS and Android OS. Check system status, arm or disarm, and operate doors and outputs. You’ll never miss an alarm event with push, voice, SMS or email notification available. You will know when other users have armed or disarmed the system – like your children coming home, or your staff locking up when leaving.

    Bosch My Alarm

    Bosch Security Products Warranty

    • Bosch security products are covered by a 3 year manufacturer warranty
    • Please Note: Exclusions are labour for Bosch Security products installed by others companies
    • CTC Communications provides a 1 year warranty on labour when the security product is installed by our team
    • Freight cost is excluded from warranty, unless the product is dead upon arrival
